Cleanrooms & Environmental Rooms

Soper’s SoftWall Cleanrooms create and maintain completely controlled clean environments, typically with positive air pressure. Our fabric Cleanroom enclosures range from non-spec’d “E” or environmental rooms (also known as white rooms or grey rooms) to fully specified ISO class air cleanliness. Modular in design and custom-designed to meet your specific material handling and process specifications, Soper’s SoftWall fabric Cleanroom enclosures are easily integrated with third party fan and filter modules.

Applications

  • Ideal for Electronics, Pharmaceutical, Medical and Food industries
  • Assembly stations
  • Packaging areas
  • Controlled processes
  • Painting rooms
  • Inspection booths

Benefits

  • Create and maintain completely controlled clean environments
  • Reduce defects
  • Eliminate dust and other airborne contaminants
  • Easy to install, dismantle, and relocate

Features

  • Manufactured of clear view polyvinylchloride (PVC)
  • Anti-static, high temperature, chemical resistant materials available
  • Rugged, anodized aluminium frame system
  • Modular design enables multiple configurations
  • Completely self-supporting or suspended from existing overhead structure
  • Increase cleanroom classification by using drop-in HEPA filter units

Downloads

Brochure - Softwall Environmental Cleanrooms

SoftWall Environmental Cleanrooms – Brochure

Cleanroom Provides Sterile Conditions

Cleanroom Provides Sterile Conditions

Softwall Partition Survey Sheet

Softwall Partition Survey Sheet

Softwall Framed Enclosure Survey Sheet

Softwall Framed Enclosure Survey Sheet

Cleanroom Survey Sheet

Cleanroom Survey Sheet

Request a Quotation

1.800.263.8334

Find out how we can create a custom solution for your business. Call us or submit a quote below.




Frequently Asked Questions

How do I determine which Soper's solution is right for me?

Our Soper’s team can help guide you in determining which solution will be best suited to your needs and requirements with one or more of our survey sheets. Our survey sheets can be found on our Resources page. Once we have received the initial input from your completed survey sheets, and if possible pictures of the potential installation area, we will go to work on developing some preliminary concepts.

Contact Soper’s today at 1-800-263-8334 or at info@sopers.com and we can help you get started!

What is your order turnaround?

The intricacy and size of the job requested will determine the length of time needed for approximate delivery. While times may vary, there are 3 levels of job categories that determine order turnaround time.

Level 1: When ordering stock items, your order will take approximately 2 days to process before shipment.

Level 2: For a standard (typical) curtain, one to two-day order entry, requiring at least one more day for drawing approval and an additional two weeks for manufacturing.

Level 3: When working with a complex project or a custom design the order entry process will take 2-3 days, followed by 1-2 weeks for drawing approval and up to 3-5 weeks for manufacturing to be completed before shipping.

Delivery times vary on geography and are approximate and installation time will vary upon application.

Contact Soper’s today to determine the level of service required for your next project.

Why Use SoftWall?

You have an in-plant environmental problem – dust, fumes, noise, temperature, cross-contamination, odour, overspray, etc. You’ve considered hiring a contractor to build a traditional drywall, concrete block, or metal clad partition or enclosure. But, have you thought of installing a Soper’s SoftWall partition or enclosure? Consider the following advantages of a Soper’s SoftWall alternative to traditional rigid wall construction.

Cost
Traditional rigid wall construction can cost anywhere from $8 to $35 per square foot. Soper’s SoftWall systems cost a fraction of what it cost to build a traditional rigid wall, leaving extra money in the budget for other concerns. Don’t forget about low future modification costs, as well.

Flexibility
Traditional rigid wall construction is difficult to modify or move. Soper’s SoftWall partitions and enclosures can be easily disassembled and reinstalled or reconfigured elsewhere to accommodate new requirements.

Installation
Installing a rigid wall can be expensive, messy and time consuming. Soper’s SoftWall Partitions and Enclosures can be installed quickly with little or often no downtime, meaning minimal interruption to production. Plus, there is no mess and aggravation typically associated with rigid wall installs.

Call your regional agent and Soper’s for a more in-depth discussion!

Is your fabric flame retardant?

Yes.

When designing your custom solution, Soper’s can meet Class 1 ASTM E 84 or NFPA 701 flammability specifications and building code requirements by matching the right fabric to your application.

Both Canada and the United States uphold strict codes and regulations that determine classifications of flame retardant fabrics. There are many testing methods and agencies that perform these tests including the National Fire Protection Association (NFPA) and American Society for Testing and Materials (ASTM). It’s important to note that flame-retardant materials are not fire proof. Here are some material examples that are used in a few of our popular product lines:

MATERIALS* SPECIFICATION USES
Vinyl Coated Polyester (VCP) Select VCP materials meet NFPA-701, CAN/ULC-S109 and Class 1 ASTM E 84 flammability specifications Soper’s SoftWall Enclosures, Partitions and Curtains
14 mil Polyvinylchloride (PVC) Clear PVC is a popular clear vinyl that is cost efficient, flexible, and durable and meets the NFPA-701 fire rating Curtains, Partitions and Welding Screens(PVC is available in clear or welding colours)
Woven Polyethylene Woven polyethylene fabric provides extremely high tensile and tear strength in relation to its light weight and meets NFPA-701 and Class 1 ASTM E 84 flammability specifications Soper’s Curtains, Partitions and Fabric Air Ducts

*Soper’s also carries a variety of specialty high temperature resistant fabrics

Contact Soper’s today for a more in-depth discussion!
